Accessory Timer

Accessory Timer - Specifications

• Timer can be set from 1 second to 60 minutes
• Can be triggered via a N.O. positive (+) trigger input signal or a N.C. negative (-) trigger device or by powering up the unit
• Relay can be programmed to activate at the start or at the end of the timing cycle
• Relay can also be set to activate for one second at the end of the timing cycle
• Relay can be programmed to pulse (flash) or be steady on
• Built in reset function to manually reset timing cycle
• Form-C relay, contacts rated 8A @ 120VAC/24VDC
• LED indicates relay is energized
• 12VDC124VDC operation (auto sensing)
• Current draw - Less than I mA (standby) or 50mA (relay energized)
• Board measures 2-718" x 2-112" (73 x 63 mm)
• Functions programmed via DIP switches - no jumpers to cut

Accessory Timer - Included

• One Programmable Timer Module

Accessory Timer

This timer is easy to setup and use with all of our driveway alarm accessories. Use the timer to have accessories activate for a specified length of time immediately after the driveway sensor detects something, or use the timer to add a delay to the accessories activation. With the easy to understand dip switches and versatility this timer allows you create the exact driveway alarm response you want.

Accessory Timer - Manuals and Support

• Accessory Timer Manual
• Wiring Timer to PSC01OA
