DA610 Mier Wireless Vehicle Sensor

Mier DA-610 Wireless Vehicle Sensor - Specifications

Mier DA-610 Driveway Sensor

• POWER REQUIREMENTS: TWO (2) SIZE AA (LR-6) BATTERIES 3.0 VOLTS DC
• OPERATING FREQUENCY: 433.92 MHZ FIXED
• ANTENNA: 1/4 WAVE MONOPOLE BOLTED INTO THE STEEL CASE. 0 DBI GAIN
• TRANSMITTER OUTPUT: 2 MILLIWATTS
• TRANSMITTER: LINX TECHNOLOGIES MODEL KH ENCODER/TRANSMITTER
• ENCODER MODULATION: AMPLITUDE ON-OFF KEYING (OOK) AT 1200 BPS.
• ADDRESS CODES: FOUR POSITION DIP SWITCH SELECTED FOR THE ENCODER
• DATA: ONE DATA BIT ENCODED WHEN BATTERY IS LOW.
• TRANSMITTER ON TIME: LESS THAN 5 SECONDS FOR ANY SINGLE ALARM
• ENCLOSURE: 18 GAUGE GALVANEAL PAINTED STEEL WITH WEATHER SEAL AND LOCKABLE LATCH CLOSURE.
• QUIESCENT CURRENT : 60 MICROAMP
• ACTIVE CURRENT: 3 MILLIAMP
• BATTERY LIFE: ABOUT ONE YEAR IN RESIDENTIAL USE.
• OPERATING TEMP: -40 DEGREES F TO + 125 DEGREES F
• WEIGHT: FOUR POUNDS
• DETECTION OF VEHICLES: DISTANCE FROM SENSOR/TRANSMITTER UNIT FOR STANDARD SEDAN MOVING AT 5 MPH= 14 FEET (MAX), 8 FEET (MID), 6 FEET (MIN)
• TRANSMISSION DISTANCE - MAXIMUM OF 1000'

Mier DA-610 Wireless Vehicle Sensor - Included

• 1 - DA-610 Wireless Vehicle Sensor

*Call for pricing on the Mier Products Driveway Alarm Receivers

Mier DA-610 Wireless Vehicle Sensor

The Mier Wireless Drive-Alert's sensor only detects cars, trucks, motorcycles, bicycles, or any large moving metal object. When a vehicle is detected, the sensor transmits a signal wirelessly to the control panel which sounds an electronic alert. An unlimited number of sensors can be used to protect multiple areas! The sensors can also be placed in or next to stationary equipment such as tractors, mobile homes, campers, gas tanks, trailers, etc. The Drive-Alert will sound an alarm if this equipment is moved, thus aiding in the prevention of theft or vandalism.

*This system is designed for driveways which are less than 1000' in length.

Mier DA-610 Wireless Vehicle Sensor - Support and Downloads

• Mier DA-600 Manual
• Whistle Sound
